Moving coil actuators do not come with a bearing system, if you would like to see actuators with a built-in bearing system please look at our moving magnet models. Or if you would like to see how we have integrated our voice coils into linear motion stages.
To determine your motion profile needs, use our linear motion calculator.
| Device Type | Moving Coil | |
| Stroke | 0.25 in | 6.4 mm |
| Radial Clearance | 0.015 in | 0.38 mm |
| Bearing Type | None | |
| Moving Mass | 1.94 oz | 55 grams |
| Total Mass | 10.9 oz | 310 grams |
| Resistance @ 20C | 3.75 ± 0.4 ohms | |
| Inductance @ 20C | 1.30 ± 0.30 mH | |
| Electrical Time Constant | 0.35 msec | |
| Motor Constant | 1.38 lbs/√watt | 6.14 N/√watt |
| Force Constant | 2.7 lbs/amp | 11.9 N/amp |
| Back EMF | 0.3 V/ips | 11.9 V/m/sec |
| Force @ 100% Duty | 5.0 lbs | 22.3 N |
| Power @ 100% Duty | 13 watts | |
| Current @ 100% Duty | 1.9 amps | |
| Force @ 10% Duty | 15.0 lbs | 66.8 N |
| Power @ 10% Duty | 118 watts | |
| Current @ 10% Duty | 5.6 amps | |
| Outside Diameter | 1.50 in | 38 mm |
| Housing Length | 1.63 in | 41.3 mm |
