To determine your motion profile needs, use our linear motion calculator.
| Device Type | Moving Coil | |
| Stroke | 0.08 in | 2.0 mm |
| Radial Clearance | 0.010 in | 0.25 mm |
| Bearing Type | Sliding Contact | |
| Moving Mass | 0.27 oz | 7.5 grams |
| Total Mass | 1.6 oz | 45.5 grams |
| Resistance @ 20C | 0.90 ohms | |
| Inductance @ 20C | 0.45 mH | |
| Electrical Time Constant | 0.5 msec | |
| Motor Constant | 0.18 lbs/√watt | 0.8 N/√watt |
| Force Constant | 0.17 lbs/amp | 0.8 N/amp |
| Back EMF | 0.02 V/ips | 0.8 V/m/sec |
| Force @ 100% Duty | 0.45 lbs | 2 N |
| Power @ 100% Duty | 6 watts | |
| Current @ 100% Duty | 2.6 amps | |
| Force @ 10% Duty | 1.35 lbs | 6 N |
| Power @ 10% Duty | 56 watts | |
| Current @ 10% Duty | 7.8 amps | |
| Outside Diameter | 1.18 in | 30 mm |
| Housing Length | 0.433 in | 11 mm |
