Rotary Voice Coil Actuator, NCC10-15-1RC-T

H2W Technologies Limited Angle Torque Motors are ideal for compact, limited angular excursion (<180º), rotary, closed loop servo applications. Unlike conventional rotary brush and brushless motors, the torquers are wound in such a way that no commutation is required for motion to occur. The result is a much simpler and more reliable system.

To determine your motion profile needs, use our rotary motion calculator.

Continuous Torque Range	20 degrees	0.35 rad
Total Mass	15.9 oz	450 grams
Housed w/ Bearings	No
Torque @ 100% Duty	40 in-oz	28.2 N-cm
Torque at 10% Duty	120 in-oz	84.7 N-cm
Power @ 100% Duty	3 watts
Power @ 10% Duty	9 watts
Torque Constant	1 in-oz/amp	2 N-cm/amp
Motor Constant	25 in-oz/sqrt(watt)	2 N-cm/sqrt(watt)
Current @ 100% Duty	1 amps	2
Current @ 10% Duty	1 amps	2
Resistance @ 20°C	5.5 ohms

Product Drawing
